HiLook 5MP 2.8mm Fixed Turret Network Camera IPC-T250H

The HiLook 5MP Fixed Turret Network Camera IPC-T250H offers clear 5MP images and efficient H.265+ compression to save bandwidth and storage. Its 120 dB true WDR ensures clear footage even in bright backlight. With an IP67 rating, it’s water and dust resistant for outdoor use. Easy to install using Power over Ethernet (PoE), it connects and powers with one cable for a hassle-free setup. This camera delivers reliable, high-quality security for your property.

Key Features

• High quality imaging with 5MP resolution
• Efficient H.265+ compression technology to save bandwidth and storage
• Clear imaging against strong back light due to 120 dB true WDR technology
• Water and dust resistant (IP67)
• Easy installation with Power over Ethernet (PoE) technology

Downloads

Download HiLook 5MP Fixed Turret Network Camera IPC-T250H Datasheet

Specifications

Camera

• Image Sensor 1/2.7" progressive scan CMOS
• Max. Resolution 2560 × 1920
• Min. Illumination Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
• Shutter Speed 1/3 s to 1/100,000 s
• Day & Night IR cut filter
• Angle Adjustment Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°

Lens

• Lens Type Fixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV

  2.8 mm, horizontal FOV 98.0°, vertical FOV 71.7°, diagonal FOV 127.0°

  4 mm, horizontal FOV 75.3°, vertical FOV 55.5°, diagonal FOV 98.2°

• Lens Mount M12
• Iris Type Fixed
• Aperture F2.0

Illuminator

• Supplement Light Type IR
• Supplement Light Range Up to 30 m
• IR Wavelength 850 nm

Video

• Main Stream

  50 Hz: 20 fps (2560 × 1920)

  25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

  60 Hz: 20 fps (2560 × 1920)

  30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)

• Sub-Stream

  50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

  60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

• Video Compression

  Main stream: H.265+/H.265/H.264+/H.264

  Sub-stream: H.265/H.264/MJPEG

• Video Bit Rate 32 Kbps to 16 Mbps
• H.264 Type Baseline Profile/Main Profile/High Profile
• H.265 Type Main profile
• Region of Interest (ROI) 1 fixed region for main stream

Network

• Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
• Simultaneous Live View Up to 6 channels
• API Open Network Video Interface, ISAPI
• User/Host

  Up to 32 users. 3 levels: administrator, operator and user

  3 user levels: administrator, operator, and user

• Client iVMS-4200, Hik-Connect
• Web Browser

  Plug-in required live view: IE 10+

  Plug-in free live view: Chrome 57.0+, Firefox 52.0+

  Local service: Chrome 57.0+, Firefox 52.0+


• Image Settings Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
• Day/Night Switch Auto, Schedule, Day, Night
• Wide Dynamic Range (WDR) 120 dB
• Image Enhancement BLC, 3D DNR

Interface

• Ethernet Interface 1 RJ45 10 M/100 M self-adaptive Ethernet port

Event

• Basic Event Motion detection, video tampering alarm, exception
• Linkage Upload to FTP, notify surveillance center, send email

General

• Power

  12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug

  PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W

• Dimension Ø110mm × 93.2 mm (Ø4.3" × 3.7")
• Package Dimension 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
• Approx. 320 g (0.7 lb.)
• With Package Weight Approx. 550 g (1.2 lb.)
• Storage Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Startup and Operating Conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Language English, Ukrainian
• General Function Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

Approval

• EMC

  FCC SDoC: 47 CFR Part 15, Subpart B;

  CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011+A1: 2014;

  RCM: AS/NZS CISPR 32: 2015;

  IC VoC: ICES-003: Issue 7;

  KC: KN 32: 2015, KN 35: 2015

• Safety

  UL: UL 62368-1;

  CB: IEC 62368-1:2014+A11;

  CE-LVD: EN 62368-1:2014/A11:2017;

  BIS: IS 13252(Part 1):2010/ IEC 60950-1: 2005

• Environment

  CE-RoHS: 2011/65/EU;

  WEEE: 2012/19/EU;

  Reach: Regulation (EC) No 1907/2006

• Protection IP67: IEC 60529-2013
