SKU: VTO6222E-P
$478inc. GST
$478inc. GST
10 customers are viewing this product
The Dahua 2-Wire & PoE Apartment Outdoor Station with keypad is designed for multi-unit residential buildings. Features directory, keypad entry, and supports multiple apartments. Highly durable and elegant, it is...
Product Badge
Product Badge
Product Badge
Please hurry! Only 20 left in stock
  • Secure On Australia

Typically shipped within 1 - 3 business days

Free standard shipping on orders over $200

Back-to-base Australian warranty

Free tech support

14-day return policy

Tags: / / / / /
Dahua 2-Wire & PoE Apartment Outdoor Station - Keypad, Multi-Unit - VTO6222E-P

Dahua

Dahua 2-Wire & PoE Apartment Outdoor Station - Keypad, Multi-Unit - VTO6222E-P

$478
Dahua 2-Wire & PoE Apartment Outdoor Station - Keypad, Multi-Unit - VTO6222E-P
Dahua 2-Wire & PoE Apartment Outdoor Station - Keypad, Multi-Unit - VTO6222E-P
Dahua 2-Wire & PoE Apartment Outdoor Station - Keypad, Multi-Unit - VTO6222E-P
Dahua 2-Wire & PoE Apartment Outdoor Station - Keypad, Multi-Unit - VTO6222E-P

Dahua

Dahua 2-Wire & PoE Apartment Outdoor Station - Keypad, Multi-Unit - VTO6222E-P

$478
Product Details

The Dahua 2-Wire & PoE Apartment Outdoor Station with keypad is designed for multi-unit residential buildings. Features directory, keypad entry, and supports multiple apartments.

  • Highly durable and elegant, it is made of aluminum panel，and has a mechanical keypad.



  • 2MP HD camera.



  • Supports 5,000 users and 10,000 cards.



  • Supports multiple unlock methods including password, IC card, and unlocks remotely.



  • Connects card readers and controllers through Wiegand.



  • Provides 12 VDC, 600 mA power.



  • IP65 rated (silicone sealant is required for the shell, see the quick start guide).



  • IK08 rated.



  • Standard PoE power supply (if the VTO device with 12 V power output needs to charge the load, it should be connected to a PSE switch that complies with the 802.3.at standard).

Downloads

View Datasheet

Technical Specifications

System

Main Processor

Embedded Processor

Operating System

Embedded Linux OS

Button Type

Mechanical

Number of Buttons

16

Basic

Screen Type

Non-touchscreen

Display Screen

2.3-inch display screen

Camera

1/2.9" 2 MP CMOS

Field of View

H:140°,V:80°, D:160°

WDR

120 dB

Noise Reduction

3D NR

Video Compression

H264，H265

Video Resolution

Main stream: 720p,WVGA, D1, CIF
Sub stream: 1080p,WVGA, D1, QVGA, CIF

Video Frame Rate

25 fps

Light Compensation

Auto white light

Day/Night

Color/B/W

Audio Compression

G.711a, G.711u, PCM

Audio Input

1

Audio Output

Built-in Speaker

Audio Mode

Two-way audio

Audio Enhancement

Echo suppression/digital noise reduction

Audio Bit Rate

16 KHz, 16 bit

Function

Communication Mode

Digital 2-wire

Verification Method

Card;Password;Remote

Card Type

IC card

Auto Snapshot

Yes (SD card is inserted in the indoor monitor or door station)

Leave Videos

NA;Yes (SD card is inserted in the indoor monitor or door station)

Storage

Supports Micro SD card (up to 256 GB)

Web Configuration

Yes

RFID

Modulation Type

ASK

Frequency Range

13.56 MHz

Max. Transmission Power

42dBuA/m @10m

Performance

Card Reading Distance

0 cm–3 cm (0"–1.18")

Casing Material

Aluminum

Capacity

Card Capacity

10,000

Port

RS-485

1

Wiegand

1

Alarm Input

1

Alarm Output

1

Power Output

1 port,12 V/600 mA

Door Bell

1

Exit Button

1

Lock Control

1

Network Port

1 × RJ-45 port，10Mbps/100Mbps network port

Alarm

Tamper Alarm

Yes

General

Appearance Color

Silver

Power Supply

48 VDC, 0.4 A, PoE (802.3af/at)

Power Adapter

Optional

Installation

Flush Mount;Surface Mount

Certifications

CE

Accessory

Flush mount box (optional);
Surface mount box (optional)

Product Dimensions

200.0 mm × 98.0 mm × 35.4 mm (7.87" × 3.86" × 1.39") (H × W × D)

Protection

IK08, IP65 (silicone sealant is needed, see the quick start guide)

Operating Temperature

–40 °C to +60 °C (–40 °F to +140°F)

Operating Humidity

10%–90% (RH), non-condensing

Operating Environment

Outdoor

Operating Altitude

Beneath 3000 m (9842.52 ft)

Power Consumption

≤ 5 W (standby), ≤ 7 W (working)

Gross Weight

0.657 kg (1.45 lb)

Storage Temperature

0 °C to +40 °C (+32 °F to +104 °F)

Storage Humidity

30%–75%(RH)
