Ruijie 1000BASE-SX SFP Transceiver Multi Mode 850nm 550M LC DDM MINI-GBIC-SX-MM850
SKU:
MINI-GBIC-SX-MM850
- $57inc. GST
$90- $57inc. GST
- Unit price
- per
Save $33
10 customers are viewing this product
Please hurry! Only 20 left in stock
Typically shipped within 1 - 3 business days
Free standard shipping on orders over $200
Back-to-base Australian warranty
Free tech support
14-day return policy
Vendor: Ruijie
Ruijie 1000BASE-SX SFP Transceiver Multi Mode 850nm 550M LC DDM MINI-GBIC-SX-MM850
Vendor: Ruijie
Ruijie 1000BASE-SX SFP Transceiver Multi Mode 850nm 550M LC DDM MINI-GBIC-SX-MM850
Ruijie MINI-GBIC-SX-MM850 1000BASE-SX SFP Optical Transceiver
The Ruijie MINI-GBIC-SX-MM850 is a 1000BASE-SX SFP transceiver module designed for cost-effective, high-speed Gigabit interconnection in data centre and campus network environments. Operating at 850nm over multimode fibre with a duplex LC connector, it supports link lengths up to 550 metres and includes digital optical monitoring (DDM) for strong diagnostic capability. Hot-pluggable and compliant with IEEE 802.3z, SFP MSA, SFF-8472, and RoHS standards. Backed by a 3-year warranty.
Highlight Features
- 1000BASE-SX, 1.25Gbps data rate
- 850nm VCSEL transmitter over multimode fibre (MMF)
- Reach: up to 550m with duplex LC connector
- Digital optical monitoring (DDM/DOM) for diagnostics
- Hot-pluggable SFP MSA compliant
- Max power consumption: 1.5W
- IEEE 802.3z Gigabit Ethernet compliant
- Class 1 laser safety and RoHS compliant
Specifications
| Optical | |
|---|---|
| Data Rate | 1.25 Gbps |
| Wavelength | 850 nm |
| Cable Type | Multimode Fibre (MMF) |
| Connector | Duplex LC |
| Reach | 550 m |
| Transmitter Type | VCSEL |
| Receiver Type | PIN |
| Max Transmit Power | 0 dBm |
| Min Transmit Power | -9.5 dBm |
| Receive Sensitivity | < -17 dBm |
| Overload Optical Power | 0 dBm |
| Min Extinction Ratio | 9 dB |
| Bit Error Ratio (BER) | 1.00E-12 |
| DDM/DOM | Yes |
| Physical | |
| Form Factor | SFP |
| Dimensions (W x D x H) | 56.5 x 13.5 x 8.5 mm |
| Weight | 35 g |
| Max Power Consumption | 1.5W |
| Environment | |
| Operating Temperature | 0°C to 70°C |
| Operating Humidity | 10% to 90% RH |
| Storage Temperature | -40°C to +85°C |
| Compliance | |
| Standards | IEEE 802.3z, SFP MSA, SFF-8472, SFF-8431, SFF-8432, RoHS |
