Ruijie Reyee 6P GE L2 Cloud Managed Industrial Switch 3x PoE+ 1x PoE++ 180W 2x SFP RG-NIS2100-4GT2SFP-HP
Vendor: Ruijie
Ruijie Reyee 6P GE L2 Cloud Managed Industrial Switch 3x PoE+ 1x PoE++ 180W 2x SFP RG-NIS2100-4GT2SFP-HP
Ruijie Reyee RG-NIS2100-4GT2SFP-HP 6-Port Cloud Managed Industrial PoE Switch
The Ruijie Reyee RG-NIS2100-4GT2SFP-HP is a compact 6-port Layer 2 cloud managed industrial switch built for demanding environments. With a wide operating temperature range of -40°C to +75°C, full aluminium casing, 6kV surge protection, and EMC Level 4 electromagnetic interference resistance, it is engineered to keep networks running in harsh industrial, outdoor, and factory settings. A 90W PoE output (up to 180W max) powers high-demand devices, while DIN rail mounting and DIP switch ERPS configuration simplify installation and failover setup. Managed via Ruijie Cloud for remote monitoring and maintenance. Backed by a 5-year warranty.
Highlight Features
- 4x GE RJ45 ports (3x PoE+, 1x PoE++) + 2x 1GE SFP uplink ports
- PoE budget: 108W default, up to 180W (web-adjustable)
- Wide operating temperature: -40°C to +75°C
- Full aluminium casing for thermal management and durability
- 6kV surge protection against voltage spikes
- EMC Level 4 protection against electromagnetic interference
- DIN rail mounting for simplified installation in enclosures
- DIP switch for instant ERPS configuration and rapid service failover
- Self-organising network (SON) for simplified setup
- PoE watchdog and port isolation
- IP40 protection against solid particles
- Ruijie Cloud remote management
- Warranty: 5 years
Hardware Specifications
| Ports | |
|---|---|
| Total RJ45 Ports | 4x 10/100/1000BASE-T |
| PoE++ Port | 1x (Port 1) |
| PoE+ Ports | 3x (Ports 2-4) |
| SFP Uplink Ports | 2x 1GE |
| PoE | |
| PoE Budget | 108W default / 180W max (web-adjustable) |
| PoE Power Pins | Port 1: 1-2(+), 3-6(-), 4-5(+), 7-8(-) Ports 2-4: 1-2(+), 3-6(-) |
| Switching | |
| Switching Capacity | 12 Gbps |
| Forwarding Rate | 8.9 Mpps |
| Environment | |
| Operating Temperature | -40°C to +75°C |
| Surge Protection | 6kV |
| EMC | Level 4 |
| IP Rating | IP40 |
| Mounting | DIN Rail |
| Software | |
| PoE Watchdog | Yes |
| Port Isolation | Yes |
| ERPS | Yes (DIP switch) |
| Cloud Management | Yes (Ruijie Cloud) |
| Layer | Layer 2 |
Downloads
FAQ
Q: How can I get notified instantly if there's a power failure?
A: You can connect a buzzer or LED to the alarm port. Then, turn on the DIP switch for alarm to activate the alarm function. This will ensure that the alarm will be triggered whenever there is a power failure in the power supply.
