Ruijie Reyee 10-Port GE Layer 2 Cloud Managed Switch 8x PoE+ 125W 2x SFP RG-NBS3100-8GT2SFP-P-V2

Ruijie Reyee RG-NBS3100-8GT2SFP-P-V2 10-Port Gigabit Layer 2 Cloud Managed PoE Switch

The Ruijie Reyee RG-NBS3100-8GT2SFP-P-V2 is a 10-port Gigabit Layer 2 cloud managed PoE switch built for enterprise and SMB deployments requiring high reliability and advanced network control. With 8x PoE+ ports (125W budget), 2x SFP uplinks, 6kV surge protection, and enterprise-class features including link aggregation, IGMP snooping, and VLAN support, it delivers robust performance for IP camera, wireless AP, and VoIP deployments. Lifetime cloud management via Ruijie Cloud. Backed by a 5-year warranty.

Highlight Features

• 8x GE PoE+ ports (802.3at/af, max 30W per port) + 2x 1GE SFP uplinks
• 125W total PoE budget
• 6kV surge protection on service ports and power connector
• IP camera and NVR recognition for CCTV networks
• Link aggregation, IGMP snooping, and VLAN support
• Multiple security policies: port isolation, broadcast storm control
• Jumbo frame support up to 9216 bytes
• PoE watchdog for automatic device recovery
• Zero-touch provisioning with SON
• Lifetime cloud management via Ruijie Cloud
• MTBF: 400,000 hours
• Warranty: 5 years

Hardware Specifications

Frequently Asked Questions

How many PoE devices can I connect to the RG-NBS3100-8GT2SFP-P-V2?

The switch has 8x PoE+ ports with a total budget of 125W and a maximum of 30W per port. For typical IP cameras drawing 10-15W, you can comfortably power all 8 ports within the budget. Devices requiring the full 30W (PoE+) can be powered on up to 4 ports simultaneously within the budget.

What is the difference between this switch and the RG-NBS3100-24GT4SFP-P-V2?

The RG-NBS3100-8GT2SFP-P-V2 is an 8-port model with 2x SFP uplinks and a 125W PoE budget, suited for smaller installations or wiring closets. The 24-port model offers 24x PoE+ ports, 4x SFP uplinks, and a 370W budget for larger deployments.

Can I manage this switch remotely?

Yes. The switch supports lifetime free cloud management via Ruijie Cloud, allowing you to monitor port statistics, configure VLANs, manage PoE, and perform firmware updates from anywhere. The Ruijie Reyee mobile app is also supported.

Does it support IP camera recognition?

Yes. The switch includes built-in IP camera and NVR recognition for easy identification of CCTV devices. It also supports PoE watchdog for automatic camera recovery and individual port reboot without requiring an on-site visit.

What SFP modules are compatible with the uplink ports?

The 2x SFP uplink ports support standard 1GE SFP modules. Ruijie-compatible options include the MINI-GBIC-SX-MM850 (multimode, 550m) and MINI-GBIC-LX-SM1310 (single-mode, 10KM).

What warranty does this switch come with?

The RG-NBS3100-8GT2SFP-P-V2 is covered by a 5-year warranty with Australian support through Secure On Australia.

Downloads

• RG-NBS3100-8GT2SFP-P-V2 Datasheet
• RG-NBS3100-8GT2SFP-P-V2 Installation Guide
