Ruijie Reyee 52-Port GE Layer 2 Cloud Managed Switch 48x PoE+ 370W 4x SFP RG-NBS3100-48GT4SFP-P-V2

Ruijie Reyee RG-NBS3100-48GT4SFP-P-V2 52-Port Gigabit Layer 2 Cloud Managed PoE Switch

The Ruijie Reyee RG-NBS3100-48GT4SFP-P-V2 is a high-density 52-port Gigabit Layer 2 cloud managed PoE switch built for large enterprise, education, and surveillance deployments. With 48x PoE+ ports delivering a 370W budget, 4x 1GE SFP uplinks, 104 Gbps switching capacity, and 6kV surge protection, it delivers enterprise-class performance and reliability. PWM fan control optimises for low noise operation. Lifetime free cloud management via Ruijie Cloud. Backed by a 5-year Ruijie Reyee manufacturer warranty.

Highlight Features

• 48x GE PoE+ ports (802.3at/af) + 4x 1GE SFP uplinks
• 370W total PoE budget
• 104 Gbps switching capacity, 77.38 Mpps forwarding rate
• 6kV surge protection on service ports and power connector
• IP camera and NVR recognition for CCTV networks
• Link aggregation, IGMP snooping, and VLAN support
• Multiple security policies: port isolation, broadcast storm control
• Jumbo frame support up to 9216 bytes
• PWM fan for optimised low-noise operation
• PoE watchdog for automatic device recovery
• Zero-touch provisioning with SON
• Lifetime free cloud management via Ruijie Cloud
• MTBF: 400,000 hours
• Warranty: 5 years

Hardware Specifications

Frequently Asked Questions

How many PoE devices can I connect to the RG-NBS3100-48GT4SFP-P-V2?

The switch has 48x PoE+ ports with a total budget of 370W. For typical IP cameras drawing 10-15W, you can power a large number of ports simultaneously within the budget. At the maximum 30W per port (PoE+), up to 12 ports can run at full load concurrently within the 370W budget.

How does this switch compare to the 24-port model?

The RG-NBS3100-48GT4SFP-P-V2 doubles the port count to 48x PoE+ ports and increases switching capacity to 104 Gbps, making it suited for large floors, campuses, or high-density camera deployments. The 24-port model is better suited for medium-sized installations.

Can I manage this switch remotely?

Yes. The switch supports lifetime free cloud management via Ruijie Cloud, allowing you to monitor port statistics, configure VLANs, manage PoE, and perform firmware updates from anywhere. The Ruijie Reyee mobile app is also supported for on-the-go management.

Does it support IP camera recognition?

Yes. The switch includes built-in IP camera and NVR recognition for easy identification and management of CCTV devices. PoE watchdog enables automatic camera recovery without requiring an on-site visit.

What SFP modules are compatible with the uplink ports?

The 4x SFP uplink ports support standard 1GE SFP modules. Ruijie-compatible options include the MINI-GBIC-SX-MM850 (multimode, 550m) and MINI-GBIC-LX-SM1310 (single-mode, 10KM).

Is the fan noisy?

The switch uses PWM fan control to dynamically adjust fan speed based on temperature, optimising for low-noise operation during normal conditions.

What warranty does this switch come with?

The RG-NBS3100-48GT4SFP-P-V2 is backed by a 5-year Ruijie Reyee manufacturer warranty.

Downloads

• RG-NBS3100 Series Datasheet
• RG-NBS3100-48GT4SFP-P-V2 Installation Guide
